TruBend 8000 Series
The TruBend 8000 Series
The TruBend Series 8000 impress with their precise versatility, a usable open height of up to 34 inches, large throat depths and a max press force of 1,000 tons.
You can process particularly large and heavy parts up to a length of 26 feet.
Innovative characteristics such as lower tool displacement, CNC-controlled crowning, and the 6-axis backgauge provide you with complete application freedom.
The work of the operator is made easier through numerous options such as the angle measuring system, the control – which is simple and intuitive to use – as well as clever ergonomic solutions such as the ToolShuttle.
Many details simplify the operator's work.
For example, the mobile control unit MobileControl shortens walking distances, since the control system's major functions can be available at up to three stations, right at the machine, with positioning suiting the user.
When dealing with very large and heavy components, TRUMPF offers, in addition to the standard bending aids and support brackets, special heavy-duty versions that can carry up to 650 lbs.
Benefits
Maximum speed with high safety and short setup times thanks to the BendGuard
Less walking around thanks to MobileControl control units
Thanks to the Tool Indicator's LED display, the operator can see at a glance at which position the bending tools have to be set up
Backgauges
Equipped for just about anything with up to 6 CNC-controlled backguage axes.
Your workpieces are positioned precisely and securely – for perfect bending results.
LCB (Laser Controlled Bending) Angle Measuring System
The LCB (Laser Controlled Bending) optical angle measuring system ensures precise angles from the first part.
LCB measures an angle in a non-contact, wear-free procedure by using a laser which projects a line onto the sheet and a camera which detects the angle.
The system, which operates independent of the tool, does not require any setup time and is easy to use.
MobileControl
MobileControl can be attached with flexibility to metallic surfaces, such as the press beam, with magnets.
This means the most important functions are always at hand and travel is reduced.
Crowning
The automatic crowning is sophisticated right up to the last detail.
You can adjust the crowning curve optimally to your bending task every 10 inches.
Support Brackets
Height adjustable support brackets make component handling easier.
The robust support brackets each have a load capacity of 660 lbs. and are available with different supports.
Bending Aids
The practical bending aid including automatic height adjustment provides valuable help – in particular when bending heavy or large parts.
It has a load capacity of up to 660 lbs.
Efficiency
Low energy consumption thanks to advanced drive technologies of the TruBend machines
The use of modern hydraulic oil eliminates the need for frequent oil changes
The automatic shutdown of the hydraulics in longer idle time reduces energy consumption
Specifications
TruBend 8230 |
TruBend 8320 |
TruBend 8400 |
TruBend 8500 |
TruBend 8600 |
TruBend 8800 |
TruBend 8010 |
|
Press Force | 253 tons | 352 tons | 440 tons | 550 tons | 660 tons | 880 tons | 1100 tons |
Bending Length | 199/238 in. | 199/238 in. | 159/199/238 in. | 159/199/238 in. | 159/199/238 in. | 238/278/317 in. | 238/278/317 in. |
Between Columns | 159/199 in. | 159/199 in. | 140/159/219 in. | 120/159/199 in. | 120/159/199 in. | 199/238/277 in. | 199/238/277 in. |
Usable Open Height | 19/26.5/34 in. | 19/26.5/34 in. | 19/26.5/34 in. | 19/26.5/34 in. | 19/26.5/34 in. | 26.5/34 in. | 26.5/34 in. |
Throat | 16.5/24 in. | 16.5/24 in. | 16.5/24 in. | 16.5/24 in. | 16.5/24 in. | 16.5/24 in. | 16.5/24 in. |
Speeds | |||||||
Y Rapid | 520 ipm | 354 ipm | 402 ipm | 378 ipm | 283 ipm | 331 ipm | 236 ipm |
Y Bending | 24 ipm | 24 ipm | 24 ipm | 24 ipm | 21 ipm | 24 ipm | 19 ipm |
Y Return | 520 ipm | 354 ipm | 402 ipm | 378 ipm | 283 ipm | 331 ipm | 236 ipm |
X Axis | 2385 ipm | 2385 ipm | 2385 ipm | 2385 ipm | 2385 ipm | 2385 ipm | 2385 ipm |
R Axis | 472 ipm | 472 ipm | 472 ipm | 472 ipm | 472 ipm | 472 ipm | 472 ipm |
Z Axis | 2835 ipm | 2835 ipm | 2835 ipm | 2835 ipm | 2835 ipm | 2835 ipm | 2835 ipm |
Precision | |||||||
Y Axis | 0.0004 in. | 0.0004 in. | 0.0004 in. | 0.0004 in. | 0.0004 in. | 0.0004 in. | 0.0004 in. |
X Axis | 0.0008 in. | 0.0008 in. | 0.0008 in. | 0.0008 in. | 0.0008 in. | 0.0008 in. | 0.0008 in. |
R Axis | 0.002 in. | 0.002 in. | 0.002 in. | 0.002 in. | 0.002 in. | 0.002 in. | 0.002 in. |
Working Range | |||||||
Y Axis | 12/20/28 in. | 12/20/28 in. | 12/20/28 in. | 12/20/28 in. | 12/20/28 in. | 20/28 in. | 20/28 in. |
X Axis | 40 in. | 40 in. | 40 in. | 40 in. | 40 in. | 40 in. | 40 in. |
R Axis | 8 in. | 8 in. | 8 in. | 8 in. | 8 in. | 8 in. | 8 in. |
